DATAKOM DFC-0115 power factor controller (12 steps), 144x144mm

Datakom DATAKOM DFC-0115 power factor controller (12 steps), 144x144mm
Datakom DATAKOM DFC-0115 power factor controller (12 steps), 144x144mm
(0)
$224.00
pcs.

Power Factor Controller DFC-0115

DFC-0115 is a high-precision device that brings the cosO value of the plants to the desired value with the help of capacitors and reactors. The device also works as a network analyzer and allows to see various AC parameters.

The device performs harmonic analysis up to component 31. The total harmonic value of all voltage and current inputs can be seen.
Compensation algorithms can be selected from various types. Thanks to the automatic learning function, it is very easy to set up and program.

A single-phase or three-phase, capacitor or reactor can be connected to each stage of the device. Device goes into standard 140x140mm slot.

FEATURES:
    • 12 and 15 level options
    • Economical and high performance
    • Capacitor or reactor connected to each stage
    • Each stage can be single-phase or three-phase
    • True RMS AC measurements, high sensitivity
    • Very easy automatic installation
    • Automatic connection error correction
    • Electronic / mechanical counter selection
    • Independent compensation of each phase
    • Commissioning / removing all required steps in one go
    • Equal aging of contactors
    • Separate VA-kW-kVAr-cos measurements of each phase
    • Total harmonic distortion (31 harmonics)
    • Generator phase input (optional)
    • Alarm relay output (optional)
    • RS-485 Modbus RTU port isolated (optional)
    • VT ratio for medium voltage applications
    • Programmable parameters from the front panel
    • Low panel depth, ease of installation
    • Wide operating temperature range
    • Fully enclosed front panel (IP54)
    • Detachable connectors

TECHNICAL SPECIFICATIONS:
Supply Voltage: 85 - 300VAC (L1-N)
                              50 - 60Hz nominal (± %10) (L1-N)
Generator Input: 70 - 300 V AC (P-N)
Measurement Inputs:
Voltage: 10 - 300 V AC (Ph-N)
                20 - 520 V AC (Ph-Ph)
Current: 0.05 - 5.50 A AC
Frequency: 30 - 100 Hz
Accuracy:
- Voltage: % 0.5 + 1 digit
- Current: % 0.5 + 1 digit
- Frequency: % 0.5 + 1 digit
- Power(kW,kVAr): %1.0 + 2 digit
- Cos: %0.5 + 1 digit
Measurement Range:
- CT Range: 5/5A to 5000/5A
- VT Range: 0.1/1 to 200.0/1
- kW Range: 0.1 kW to 6.5MW
Power Consumption: < 10 VA
Loading:
- Voltage Inputs: < 0.1VA per phase
- Current Inputs: < 0.5VA per phase
Number of Steps: 12-15
Relay Outputs: 5A @ 250V A
Serial Port:
Signal Type: RS-485
Communication: Modbus RTU
Baud Rate: 2400-115200 selectable
Isolation: 500V AC, 1 minute
Operating Temperature: -20°C to +70 °C (-4 to +158 °F)
Maximum Humidity: %95 non-condensing.
Degree of Protection:
- IP 54 (Front Panel)
- IP 30 (Rear Panell)
Enclosure:
- Non-flammable,
- ROHS compliant,
- Flame retardant,
- High temp. ABS/PC
- UL94-V0
Installation: Flush mounting with rear brackets.
Dimensions: 164x164x69mm (WxHxD)
Panel Cutout: 140x140 mm
Weight: 450 gr (approx.)
EU Directives:
- 2006/95/EC (LVD)
- 2004/108/EC (EMC)
Norms of References:
- TS-EN 61010 (safety)
- TS-EN 61326 (EMC)


WE DO NOT SHIP THIS DATAKOM PRODUCT TO USA AND CANADA
10.01.19 временно не продаем так как у датакома с ними технические проблемы. Меняют на 0112.
